51.2V WALL MOUNTED LITHIUM ENERGY STORAGE BATTERY
Product Advantages
●Built-in LiFePO4 Battery cells.Large capacity,long cycle life,high safety, environmental protection
● Intelligent communication
●Built-in BMS control board
| 产品型号
Produot Model |
LN-48100 |
| 标称电压
Nominal voltage |
51.5V |
| 标称容量
Nominal capacity |
100Ah/5120Wh |
| 电芯类型
Cell type |
磷酸铁锂 (LiFePO₄ ) |
| 组合方式
Composition |
16S1P |
| 充电截止电压
Charging cutoff voltage |
58.4V |
| 放电截止电压
Discharge Cut-off Voltage |
40V |
| 最大持续放电电流
Maximum continuous discharge current |
100A |
| 瞬间放电电流
Instantaneous discharge current |
200A |
| 显示屏
Display |
LCD显示屏/触摸显示屏
LCD display screen/touch screen display screen |
| 标准充电电流
Standard charging current |
<50A |
| 标准放电电流
Standard discharge current |
100A |
| 充电适合温度
Charge suitable temperature |
0℃~45℃ |
| 放电适合温度
Discharge suitable temperature |
-20℃~65℃ |
| 电池组尺寸
Battery pack size |
435*153*700mm |
| 包装尺寸
Package size |
535*253*800mm |
| 电池组净重
Net weight of battery pack |
48.5Kg |
| 电池组毛重
Gross weight of battery pack |
58.5Kg |
| 通讯接口
Communication interface |
CAN/RS232/RS485 |
| 冷却方式
Cooling method |
风冷
Forced air cooling |
| 运输分类
Transport classificatior |
UN38.3/MSDS/海运/空运
UN38.3/MSDS/Sea/Air |
| 电池保护功能
Battery protection function |
过流、过压、过充、过放、短路等
Overcurrent,overvoltage,overcharging,overdischarge,short circuit,etc |
